PS5: How to add an SSD M.2 to the console stepper, requirements, materials and precautions to take

The PS5 Firmware Update September 2021 has added the possibility, to be able to expand the storage of the console. It may 825 GB that includes the new generation system -Something less if we subtract the operating system- I look short for installing several games. And, if you do not want to be erasing and adding constantly, you will be interested in putting a port that increases the size.

Unlike it occurred with PS4, it was enough to install an external HDD formatted, Here the system is somewhat more difficult , since we have to open the console cover and insert a SSD M.2 into its port in ps5 so you can expand the memory space. If you do not know what it is, the summary is that it is a type of high-speed solid state unit that, at the moment, is the only way to expand the console memory to be able to save and enjoy ps5 and ps4 games directly from SSD M.2 storage and move free games between storage options.

Keep in mind that not all SSD M.2 are compatible and that a dissipation of effective heat is required.

From the PlayStation blog indicate the requirements to be taken into account to use a device of these characteristics and their sizes.

As we say, the use of an M.2 SSD with your PS5 console requires an effective heat dissipation through a cooling structure, such as a heatsink and heat transfer sheet. You can do it on your own, and there are also SSD M.2 systems with structures included in the mechanism itself . To know how to place the heat dissipation mechanism, they recommend consulting the instructions thereof, although they put three chops that serve as an example, according to the model.

PlayStation indicates some detail to consider, in addition to urging the seller or manufacturer to see information. SIE does not guarantee that all devices comply with the specifications described in the console and do not assume responsibility for the performance or use of third-party products. In addition, they point out that not all games can be played with the same performance provided by the internal SSD of ultra-high speed of the PS5 console, even when the sequential reading speed of the SSD M.2 is greater than 5500 MB / s.

Which means that the games that you have in the internal storage can, for example, have longer load times than if they were on the console itself.

Is COOLING Your SSD A MISTAKE? How to install an SSD M.2 to my PS5

Again, following the guidelines of the Official Blog of PlayStation, we go back to your instructions for assembly. Before putting ourselves, we will need the following instruments, in addition to the aforementioned storage capacity and the dissipator.

A well-lit room with a table on which you can work. A Phillips type 1 screwdriver or a star screwdriver. A small flashlight (optional).

IMPORTANT : Before starting the process, play a metallic object connected to ground to discharge the static electricity of the body. If not, the SSD M.2 or the console could be damaged.

Then we leave you a video with the process to be done, so that it is all clearer and more explanatory. And just below you can see the instructions for use provided by PlayStation.

  1. Turn off your PS5 console. Next, remove all cables and devices from your PS5 console. Wait a moment that your PS5 console is cooled.
  2. Place your PS5 console on a flat surface with a protective cover and remove the base.
  3. Place your PS5 console so that the PS logo is oriented down and the power button is oriented in the direction contrary to you.
  4. Hold the edge of the lower right corner with the right hand and the edge of the upper left corner of the cover with the left hand.
  5. Gently raise the lid with your right hand.
  6. Slide the cover with the left thumb while using the left hand to stabilize the PS5 console.
  7. Remove the screw from the expansion slot cover, and then remove the cover.
  8. Remove the screw with care. Move the separator to the corresponding slot according to the size of your SSD M.2.
  9. Subject the edge of your SSD M.2, allow it with the expansion connector notch, and then insert it firmly until the end, starting diagonally up.
  10. Tilt your SSD M.2 down and set it to the separator with the screws. Make sure your refrigeration structure does not obstruct the screw.
  11. Place the cover of the expansion slot and see it with the screw. If the slot cover does not close properly, your refrigeration structure is likely to exceed the size requirements.
  12. Replace the cover to a torque of centimeters from the top edge and slide it until it clicks into place. You will hear a click when the cover lace perfectly.
  13. Connect the AC power cord, cables and base. Next, connect the power. When the PS5 console is turned on, the Format Guide appears. Follow the instructions that appear on the screen to format your SSD M.2.

If it is the first time you use the SSD M.2 in PS5, you will have to format your SSD M.2 after installation. Beware, since if you have a saved fact, you will be lost in the process. Finally, from PlayStation insist: Do not use an M.2 SSD without a heat dissipation mechanism, such as a heat sink or heat transfer sheet.
